Galvanized Steel Triangle Fence Panel Anti-Cut Security Mesh

Categories Triangle Fence Panel
Brand Name: YUANHAI
Model Number: YH-005
Certification: ISO9001:2015
Place of Origin: Hebei Province,China
MOQ: 100 PCS
Price: US$3~20
Payment Terms: L/C,T/T
Supply Ability: 10000 Pcs 7 days
Delivery Time: 5-8 work days
Packaging Details: By pallet or as demand
Material: Galvanized Steel
Wire Diameter: 4.0mm - 6.0mm
Height: 1.2m - 3.0m
Width: 2.0m - 3.0m
Surface Treatment: Hot-Dip Galvanized
Security Level: High Anti-Cut
Application: /Prison/Industrial
Sample: For Free
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Galvanized Steel Triangle Fence Panel Anti-Cut Security Mesh

High Security Triangle Fence Panel Anti Cut Wire Mesh For Perimeter Protection
Product Specifications
AttributeValue
MaterialGalvanized Steel
Wire Diameter4.0mm - 6.0mm
Height1.2m - 3.0m
Width2.0m - 3.0m
Surface TreatmentHot-Dip Galvanized
Security LevelHigh Anti-Cut
Application/Prison/Industrial
SampleFor Free
Triangle Security Fence Panel Crash Rated Tamper Proof Hot Dip Galvanized Coating
Product Overview
Our Triangle Security Fence Panel is engineered for maximum perimeter protection in high-risk facilities. Featuring a patented V-shaped triangular mesh design, this anti-climb, anti-cut fencing system exceeds international crash ratings (IWA 14-1 and PAS 68 standards) while providing superior tamper resistance. The hot-dip galvanized coating (minimum 300g/m² zinc) ensures 25+ years of corrosion-free performance in coastal or industrial environments.
Technical Specifications
ParameterSpecification
MaterialHigh-tensile steel wire (Grade 550MPa+)
Wire Diameter5.0mm (vertical), 6.0mm (horizontal)
Mesh Design100mm x 50mm triangular openings
CoatingHot-dip galvanized (300g/m²) + optional PVC
Impact Resistance50kJ crash rating
Panel Size2.4m(H) x 3.0m(W) ±1% tolerance
Frame60x40mm rectangular steel tubing
Security FeaturesAnti-climb, anti-cut, no foot/hand holds
Applications
  • Critical Infrastructure: Nuclear plants, airports, bases, border crossings, embassies, data centers
  • High-Security Facilities: Prisons, detention centers, courthouses, VIP residences, bank vault perimeters
  • Industrial Protection: Oil/gas facilities, power substations, ports, rail yards, truck depots
Key Advantages
  • -Grade Security: V-shaped mesh deflects cutting tools and prevents climbing (tested to BS EN 10223-3), 50mm narrow apex angles eliminate grip points
  • Crash-Proven Performance: Absorbs and redistributes impact energy (certified to PAS 68 vehicle impact standards), maintains structural integrity after collision
  • Zero Maintenance Durability: 300g/m² galvanization protects against salt spray (2000hrs salt fog test), optional PVC coating for chemical resistance
  • Rapid Deployment: Pre-assembled panels with clamp-on brackets (50% faster install than welded systems), modular design allows curved/angled configurations
Production Process
Our Triangle Security Fence Panels are manufactured through a meticulously controlled production process that begins with high-quality low-carbon steel wire rods (Grade Q195/Q235), which undergo rigorous material testing including spectrometer analysis and tensile strength verification. The wire drawing process utilizes multi-pass cold drawing to achieve precise diameters (5.0-6.0mm) with ±1mm tolerance, followed by automated CNC welding using German-made equipment that ensures consistent V-shaped mesh formation with ≥1.5KN pull-out strength per weld point. Each panel then receives a durable 300g/m² hot-dip galvanized coating (85μm minimum) through a carefully monitored 450°C zinc immersion process, with optional PVC coating (0.4-0.6mm) available in standard colors. The final assembly incorporates robotic welding of 60×40mm rectangular steel tubing frames, with 100% dimensional inspection (±2mm tolerance) and load testing (500kg static pressure) before weatherproof packaging.
Frequently Asked Questions
How long does this fence last?
At least 25 years, even near the ocean. With extra coating, over 35 years.
Can someone climb over it?
Very hard! The triangle shape gives no places to put hands or feet.
How fast can it be installed?
Much faster than normal fences - about 50% quicker because panels come ready.
Does it need maintenance?
Almost none! Just check it sometimes like you check your house walls.
Is it expensive?
Costs more at first but saves money because it never needs replacing.
Can I get a sample?
Yes, we can send small samples or show you nearby projects.
