| Categories | Video Transmitter |
|---|---|
| Brand Name: | Kimghz technology |
| Model Number: | KH-ALV3306AC |
| Certification: | CE |
| Place of Origin: | Original/CHINA |
| MOQ: | 10 Pieces |
| Price: | negotiation |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 10000pieces/month |
| Delivery Time: | 2-5days |
| Packaging Details: | International Standard Packing |
| Model: | KH-ALV3306AC |
| Frequency: | 3060MHz~3500MHz |
| Input Voltage: | 7-26V |
| Power Output: | 7W |
| Channels: | 64CH |
| Output Voltage: | 5V |
| Range: | 3060MHz~3500MHz |
| Weight: | 40.4g |
| Dimensions: | 50*38*16mm |
| Company Info. |
| Shenzhen Xinhu Communication Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
High-stability wireless video transmission module featuring stable transmission and 3060MHz-3500MHz frequency coverage for professional drone applications.
This advanced 3.3GHz FPV Video Transmitter with adjustable power output operates from 3060MHz to 3500MHz, designed for reliable, low-latency, long-range drone video transmission in professional and industrial UAV applications.
The 3.3G 64-channel VTX is a high-performance wireless video transmission module specifically engineered for drone applications, providing stable and reliable video signal transmission with flexible parameter customization. Supporting 7-26V wide voltage input, it adapts to various drone power supply systems and features a dedicated LED display for intuitive real-time monitoring of working parameters.
Compared to standard single-channel or fixed-parameter VTX modules, this product offers 8 selectable bands and 8 channels per band, totaling 64 channels, which significantly enhances anti-interference capability and avoids signal conflicts in complex flight environments.
| Brand Name | Kimghz technology |
|---|---|
| Model Number | KH-ALV3306AC |
| Frequency | 3060MHz~3500MHz |
| Power Output | 6 Watt |
| Output Voltage | 5V |
| Power Supply | 7-26V |
| Antenna Connector | SMA connector |
| Extra Feature | IRC |
3.3G frequency band with 8 selectable bands (A-H) and 8 channels per band, totaling 64 channels for strong anti-interference and flexible signal transmission
Supports 2 high-power levels (2000mW and 7000mW) and 0dBm P-mode, with convenient power switching via button operation (4-second press to enter, short press to adjust)
7-26V input voltage range, compatible with various drone power supply systems for strong versatility
Designed with dedicated heat sink for optimal thermal management, ensuring stable operation under long-term high-load transmission conditions
Supports pit mode for safe ground debugging with flexible entry/exit methods via Betaflight or button operation
|
